Test Socket

Semiconductor test sockets serve as a critical interface connecting devices to test systems, demanding highly stable contact performance and exceptional reliability. We design and manufacture custom test sockets optimized for diverse testing environments, helping our customers enhance product quality and maximize testing efficiency.

Core Strengths

High Pin Count & Large Body Socket Machining Leveraging our extensive experience in manufacturing high-pin-count and large-package sockets, we reliably produce components of various sizes and complex structures (Max 240 x 240mm)

Material Versatility We are capable of processing a wide range of engineering plastics and metallic materials, providing optimized material solutions tailored to each customer's specific testing environment.

Fine Feature Machining Our precision machining technology enables the realization of fine pitches and micro-features, effectively supporting high-density semiconductor packages.

Meldin

Torlon

PEEK & Meldin

ULTEM

CERAMIC

SUS

Spring Force	Initial Force Recommended Stroke Full Stroke	2.5gf 0.70mm @ 15.5gf 0.90mm @ 19.0gf
Material Spec	Barrel Top Plunger Bottom Plunger Spring	PBT / Gold plated SK4 / Gold plated Becu / Gold plated SWP / Gold plated
Mechanical Spec	Pointing Accuracy Operating Temperature Spring Life Expectancy	± 50um -25°C ~ +125°C 200K <
Electrical Spec	DC Resistance (Avg) Current Rating Band Width Self Inductance Capacitance	<80mΩ 2 amps continuous -1 dB @ 18.11 GHz 0.93nH 0.52pF
